Heavy Duty Soluble Oil for Metal Machining
VP650P is a heavy-duty soluble oil for ferrous and non-ferrous metal machining Some machinists desire to continue to use "old fashioned" soluble oils. With these products, the majority of the lubricating and coolant is done with mineral oil with far less performance added materials contained in the product. VP 605P is not recommended for high pressure applications however on manual equipment and slow moving processes where hydrodynamic lubrication is desired over EP/AW additive chemistry, VP 650P is an excellent choice.
Contact Us Today:
1 (800) 244-9004
5 gal. pail
55 gal. drum
275 gal. tote
Features & Benefits
Characteristics
- Contains a synthetic ester that enhances bio-stability and corrosion protection
- EP Fortified
- Heavy duty soluble oil
- For machining all ferrous and non-ferrous material
Benefits
- Excellent corrosion protection
- Chemically balanced for excellent hard water tolerance
- Contains bio-resistant additives to control rancidity by eliminating the growth of bacteria and fungi
- Outstanding surface finish
Properties
| Appearance | Amber/Blue Liquid |
| Diluted Appearance | Macro Emulsion Liquid |
| Solubility | Complete |
| Odor | Mild Industrial |
| Specific Gravity | .96 |
| Concentrate pH | 9.4 |
| pH, 5 % dilution | 9.3 |
| Freeze/Thaw Cycles | Passed 3x |
Questions About Our Products?
Contact Our Sales Engineers.
Our Sales Engineers are widely regarded as the most competent and responsive in the business: they know the material, the workpiece, the tools and the fluids that you need to make it right. Together with our Field Application Engineers, they’re available with on-site assistance and technical support when you need it.
Contact Us Today:
1 (800) 244-9004
Applications & Usage
ValCOOL recommends using Val-U-Clean or K-5-P cleaner before adding VP650P to a machine.
The recommended concentration for VP650P is 5-10% for optimum results. However, results for any operation can only be determined through testing.
Maintaining the coolant at its optimum concentration is achieved through daily refractive index checking.
No special precautions are necessary with respect to seals or valves.
For Use In:
Material
- Aluminum Machining
- Nickle/Chrome Alloys
- Stainless
- Copper Yellow Metals
Machining Operation
- Milling
- Drilling
- Tapping
- Deep Hole Drilling
Specifications
| Classification: | Soluble Oil |
| Recommended Concentration | 5 – 10% |
| Refractive Index Range | 5.0 – 10.0 |
| Refractive Index Multiplier Factors | 1.0 |
| Available Color | Amber or Blue |
| Fragrance | Mild odor |
Additional Details
Metal Compatibality
- Steel
- Titanium
- Nickel Alloys
- Cast Iron
- Aluminum
- High Carbon
- Stainless Steel
- Copper
- Plastics
- High Temp Alloys
- Brass
- Inconel
Health & Safety
See the most recent SDS which is available directly from ValCOOL, your local representative or authorized distributor. ValCOOL uses only raw materials not listed as carcinogenic by IRAC.
Refractive Index Monitoring
1.0 x multiplier
| Percentage | Ratio | Refractometer Reading |
| 5 | 19 to 1 | 5.0 |
| 10 | 9 to 1 | 10.0 |
| 15 | 6 to 1 | 15.0 |
| 20 | 4 to 1 | 20.0 |
Fluid compatibility and machinability should always be tested first; as fluid concentration, metal alloy, and machining operation are variable.
